Cummins 5633492 Air Brake Compressor Kit - 1 - wisentpartscenter.com

Description

3690864RX is a Genuine Cummins ReCon single-cylinder air brake compressor for select 15L Cummins ISX / QSX and X15 applications. The RX suffix identifies this as a Cummins ReCon remanufactured part, not a basic aftermarket rebuild. This compressor supplies compressed air for the truck’s air brake system and other air-operated components. Verify 3690864RX by ESN, original compressor number, engine model, gear/drive setup, mounting flange, air line routing, coolant line routing, and the supersession list shown on this page. Air compressor replacement is labor-heavy, so correct matching matters; the wrong compressor can create fitment issues, slow air build, oil carryover, leaks, or repeat removal.

Purpose of the Part

The air brake compressor is engine-driven and builds compressed air for the brake reservoirs. It works with the governor, air dryer, reservoirs, and safety valves to maintain proper operating pressure. When the compressor output drops or the compressor passes too much oil, the truck may build air slowly, cycle the air dryer too often, or fail air-system tests.

Issue Symptoms / When to Replace

Common signs that 3690864RX may need inspection or replacement include:

  • Slow air pressure build-up
  • Low air warning staying on longer than normal
  • Compressor not reaching governor cut-out pressure
  • Excessive oil in the discharge line, wet tank, or air dryer
  • Repeated air dryer purging or heavy oil/water contamination
  • Air leaks at the compressor head, fittings, or discharge side
  • Abnormal compressor noise, overheating, or poor air recovery after brake use
  • Failed compressor output test after checking air leaks, governor, dryer, and lines

No reliable part-specific electronic fault codes were found for 3690864RX. Air compressor problems are usually confirmed with air build-time checks, leak tests, governor cut-in/cut-out verification, discharge line inspection, and air dryer condition.

Brand Information

Cummins is the OEM engine manufacturer for ISX and X15 platforms and supplies engine-mounted air-system components for those applications. Genuine Cummins is preferred for air compressor replacement because the compressor must match the engine gear train, mounting flange, oil/coolant routing, and air-system demand. A cheaper compressor can cost more if it causes repeat slow-air complaints, oil carryover, or another removal.

Installation Notes

Before replacing 3690864RX, confirm the ESN, original compressor number, and supersession list shown on this page. Drain system air pressure and follow lockout safety procedure before removing air lines. Inspect the governor, air dryer, discharge line, fittings, coolant lines, oil supply/drain paths, and mounting surface. If the old compressor failed from oil carryover or contamination, the discharge line and air dryer should be inspected before the truck goes back into service. After installation, verify air build time, governor cut-in/cut-out, leaks, and oil carryover. Refer to Cummins QuickServe or the OEM service manual for torque specs and final test procedure.

How to Identify an OEM Part

A Genuine Cummins 3690864RX air compressor should be verified by the Cummins part-number label, original packaging, compressor tag or casting identification, drive gear setup, mounting flange, and port layout. Match the removed compressor to 3690864RX and to the supersession list shown on this product page. Do not rely on appearance only, because similar WABCO-style compressors can differ by gear tooth count, drive configuration, discharge port, coolant routing, or application.
